Siemens SIMATIC NET SCALANCE W700 User Manual

Description
2.8 Power over Ethernet (PoE)
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 08/2018, C79000-G8976-C267-13
39
Table 2- 3 Fitting connectors
PIN
Color of the
wire
CAT5
Color of the
wire
CAT6a
Use
Power over
unused wires
(10/100 Mbps
only)
Phantom power
1
Yellow
Green/white
Data
Data/power
2
Orange
Green
Data
Data/power
3 White Orange/white Data Data/power
6
Blue
Orange
Data
Data/power
4
Blue
Power
unused at 10/100 Mbps
5
Blue/white
Power
unused at 10/100 Mbps
7
Brown/white
Power
unused at 10/100 Mbps
8
Brown
Power
unused at 10/100 Mbps
LEDs for PoE on the SCALANCE W700 device
When the SCALANCE W700 device is supplied by PoE, the green "PoE" LED is lit on the
SCALANCE W700 device.
