Technical specifications
SCALANCE WxM766
72 Operating Instructions, 03/2022, C79000-G8976-C617-03
Technical specifications
Wireless interface
Antenna connector
Quantity
2
Design
N-Connect socket
Impedance
50 Ω nominal
Permitted antenna wire lengths
< 30 m
Frequency range
2412 ... 2480 MHz
4920 ... 5875 MHz
Electrical data
Direct 24 VDC supply
Supply voltage from socket
24 VDC Safe Extra Low Voltage (SELV)
Type of current
Permitted
range
±30 %
16.8 to 31.2 VDC
Design
M12 socket, L-coded
Properties
Not galvanically isolated
Supply voltage from PoE
Supply voltage
48 VDC
Type of current
Permitted range
36 to 57 VDC
Design
M12 socket, X-coded
Properties
Galvanically isolated
Fusing
2.5 A / 24 V DC
1 A / 48 V PoE
Current consumption
24 V DC/ maximum
550 mA
PoE 48 V / maximum
270 mA
24 V DC Sleep Mode / maximum
12.5 mA
Active power loss
24 V DC/ maximum
13.2 W
PoE 48 V / maximum
12.96 W
24 V DC Sleep Mode / maximum
300 mW
Digital input
Quantity
1
Design
M12 socket, A-coded
Rated voltage
24 V DC
Safety extra-low voltage (SELV)
Status "0"
-30 to 3 V DC
Status "1"
10 to 30 V DC
Max. input current
8 mA
Max. cable length
< 3 m
Cables should be routed in pairs
Properties
Input isolated from electronics
