Operating
SIMATIC Rack PC IL 40, Getting Started
3-4 A5E00171493-02
3.7 Floppy Disk Drive
Caution
Risk of Data loss!
You must not press while the eject button the drive's green access LED is lit.
Do not use the disk drive when the Rack PC IL is exposed to vibrations and
shock.
3
2
1
5
6
4
7
1 = Insertion direction
2 = Label area
3 = Write protection tab for a 1.44 Mbyte floppy disk
4 = Identification of a 1.44 MB floppy disk or write protect switch on a 120 MB floppy disk
5 = Eject button for inserted floppy disks
6 = Disk is write-protected
7 = Disk is not write-protected
