NCK alarms
11/2006 Overview of Alarms
2-49
© Siemens AG, 2006. All rights reserved
SINUMERIK, SIMODRIVE Diagnostics Manual (DA), 11/2006 Edition
4180 Invalid M function number assigned to enable ASUP
Definitions: An invalid M function number has been assigned for activation of ASUP. An illegal M number has been
assigned in machine data $MN_EXTERN_M_NO_SET_INT or
$MN_EXTERN_M_NO_DISABLE_INT for the configuration of the M number range for
activation/deactivation of the interrupt program.
Reaction: Mode group not ready.
Channel not ready.
NC Start disable in this channel.
Interface signals are set.
Alarm display.
NC Stop on alarm.
Remedy: Check machine data $MN_EXTERN_M_NO_SET_INT and $MN_EXTERN_M_NO_DISABLE_INT.
Program
Continuation:
Switch control OFF - ON.
4181 Channel %1 invalid assignment of an M auxiliary function number
Parameters: %1 = Channel number
Definitions: In machine data $MC_AUXFU_ASSOC_M0_VALUE or $MC_AUXFU_ASSOC_M1_VALUE, a
number has been specified for the configuration of a new predefined M function which is occupied by
the system, and cannot be used for an assignment. (M0 to M5, M17, M30, M40 to M45).
Reaction: Mode group not ready.
Channel not ready.
NC Start disable in this channel.
Interface signals are set.
Alarm display.
NC Stop on alarm.
Remedy: Configure an M function in machine data $MC_AUXFU_ASSOC_M0_VALUE or
$MC_AUXFU_ASSOC_M1_VALUE which is not occupied by the system (M1 to M5, M17, M30, M40
to M45).
Program
Continuation:
Switch control OFF - ON.
4182 Channel %1 invalid M auxiliary function number in %2%3, MD reset
Parameters: %1 = Channel number
%2 = MD identifier
%3 = If required, MD index
Definitions: In the specified machine data, a number has been specified for the configuration of an M function
which is occupied by the system, and cannot be used for an assignment. (M0 to M5, M17, M30, M40
to M45 and also M98, M99 with applied ISO dialect). The value set by the user has been reset to the
default value by the system.
Reaction: Mode group not ready.
Channel not ready.
NC Start disable in this channel.
Interface signals are set.
Alarm display.
NC Stop on alarm.
Remedy: Configure an M function in the specified machine data which is not occupied by the system (M0 to M5,
M17, M30, M40 to M45 and also M98, M99 with applied ISO dialect).
Program
Continuation:
Clear alarm with the RESET key. Restart part program
