Overview of Alarms 11/2006
NCK alarms
2-50
© Siemens AG, 2006. All rights reserved
SINUMERIK, SIMODRIVE Diagnostics Manual (DA), 11/2006 Edition
4183 Channel %1 M auxiliary function number %2 used several times (%3 and
%4)
Parameters: %1 = Channel number
%2 = M auxiliary function number
%3 = MD identifier
%4 = MD identifier
Definitions: In the specified machine data, a number has been used several times for the configuration of an M
function.
Reaction: Mode group not ready.
Channel not ready.
NC Start disable in this channel.
Interface signals are set.
Alarm display.
NC Stop on alarm.
Remedy: Check the specified machine data and create a unique assignment of M auxiliary function numbers.
Program
Continuation:
Switch control OFF - ON.
4184 Channel %1 illegally predefined auxiliary function in %2%3, MD reset
Parameters: %1 = Channel number
%2 = MD identifier
%3 = If required, MD index
Definitions: In the specified machine data, a predefined auxiliary function has been illegally configured.
The value set by the user has been reset to the default value by the system.
Reaction: Mode group not ready.
Channel not ready.
NC Start disable in this channel.
Interface signals are set.
Alarm display.
NC Stop on alarm.
Remedy: Configure a valid value in the specified machine data.
Program
Continuation:
Clear alarm with the RESET key. Restart part program
4185 Channel %1 illegal auxiliary function configured %2 %3 %4
Parameters: %1 = Channel number
%2 = Type of auxiliary function
%3 = Extension
%4 = Auxiliary function value
Definitions: An auxiliary function has been illegally configured.
Predefined auxiliary functions cannot be reconfigured by user-defined auxiliary functions.
Reaction: Mode group not ready.
Channel not ready.
NC Start disable in this channel.
Interface signals are set.
Alarm display.
NC Stop on alarm.
Remedy: Reconfigure the auxiliary function.
Program
Continuation:
Clear alarm with the RESET key. Restart part program
