Overview of Alarms 11/2006
NCK alarms
2-58
© Siemens AG, 2006. All rights reserved
SINUMERIK, SIMODRIVE Diagnostics Manual (DA), 11/2006 Edition
4338 Channel %1 invalid transformation type '%2' in toolholder %3 for
orientation transformer %4
Parameters: %1 = Channel number
%2 = Transformer type
%3 = Number of the orientable toolholder
%4 = Number of the orientation transformation that is to be parameterized with the orientable
toolholder
Definitions: The parameters of the orientation transformation are taken over from the data of an orientable
toolholder. This orientable toolholder contains an invalid transformation type. (Types T, P and M are
permissible).
Reaction: Correction block is reorganized.
Interface signals are set.
Alarm display.
NC Stop on alarm at block end.
Remedy: Enter a valid transformation type.
Program
Continuation:
Clear alarm with the RESET key. Restart part program
4340 Channel %1 block %2 invalid transformation type in transformation no.
%3
Parameters: %1 = Channel number
%2 = Block number, label
%3 = Transformation number
Definitions: An invalid, i.e. undefined, number was entered in one of the machine data TRAFO_TYPE_1 ...
TRAFO_TYPE_8. This alarm also occurs if a certain type of transformation is only impossible on the
type of control used (e.g. 5-axis transformation on a SINUMERIK 802D).
Reaction: Correction block is reorganized.
Interface signals are set.
Alarm display.
NC Stop on alarm at block end.
Remedy: Enter a valid transformation type.
Program
Continuation:
Clear alarm with the RESET key. Restart part program
4341 Channel %1 block %2 no data set available for transformation no. %3
Parameters: %1 = Channel number
%2 = Block number, label
%3 = Transformation number
Definitions: Only a limited number of machine data sets (usually 2) is available for each related group of
transformations (e.g. orientation transformations, Transmit, Tracyl, etc.). This alarm is output if an
attempt is made to set more transformations from a group.
Example:
Two orientation transformations are allowed. The machine data contains e.g.:
TRAFO_TYPE_1 = 16 ; 1st orientation transformation
TRAFO_TYPE_2 = 33 ; 2nd orientation transformation
TRAFO_TYPE_3 = 256 ; 1st transmit transformation
TRAFO_TYPE_4 = 20 ; 3rd orientation transformation ==> This entry triggers alarm
Reaction: Correction block is reorganized.
Interface signals are set.
Alarm display.
NC Stop on alarm at block end.
Remedy: Enter valid machine data.
Program
Continuation:
Clear alarm with the RESET key. Restart part program
