Siemens SIMOTICS GP

43
Series F
A
1
B
2 3
B
2 3
A
1
A
1
B
2 3
Snap hook
(use with rope)
Screw clamp
(use with harness)
Maximum permissible tilt during
handling: 15°
15°
1
5
°
MAX
3
Open harness
with eyelets
2
Rope and hooks
1
Ring harness
Lift manually
(weight £ 15 kg)
M
Lift as per diagram A
A
Lift as per diagram B
B
M05 M1 M2 M3 M4 M5
F10 MA-B——M M
F20 A-B — —
M (P63...P90)
M
A-B
(P100...P112)
F30 A——AA
F40 A-B — A-B A-B
F50 — A-B — A-B A-B
F60 — A-B A-B A-B
F70 — A-B A-B A-B
F80 — A-B A-B A-B
F90 — A-B A-B A-B
Reccomended:
solution A for positioning; solution B for positioning and handling.
