Maximum permissible tilt during
handling: 15°
15°
1
5
°
MAX
1
Ring harness
Lift manually
(weight £ 15 kg)
M
Lift as per diagram A
A
M05 M1 M2 M3 M4
S101 MA—MM
S201 MA—MM
S301 MA—MM
S401 AAA
S501 AAA
Reccomended:
solution A for positioning.
