2.1.4 Shaft height 160 – water cooled
Table 2-5 1PH8 shaft height 160, forced ventilation (basic data)
Motor type Supply voltage P
rated
kW
M
rated
Nm
I
rated
A
U
rated
V
f
rated
Hz
n
rated
r/min
cos Φ η

J
kgm
2
P_cool
kW
m
kg
1PH8165-5□F2□
Y connection
SLM/BLM 400 V 55 350 146 310 50 1500 0.743 0.938 0.183 4.1 260
ALM 400 V 64 350 146 361 58.3 1750 0.742 0.94
SLM/BLM 480 V 73 350 146 412 66.7 2000 0.74 0.94
ALM 480 V 81 350 145 452 73.3 2200 0.739 0.941
1PH8165-7□F2□
Y connection
SLM/BLM 400 V 70 445 179 325 50 1500 0.736 0.93 5.1
ALM 400 V 80 435 176 377 58.3 1750 0.735 0.932
SLM/BLM 480 V 89 425 174 428 66.7 2000 0.734 0.932
ALM 480 V 96 415 171 468 73.3 2200 0.734 0.928
1PH8165-5□G2□
Y connection
SLM/BLM 400 V 77 370 178 357 66.7 2000 0.738 0.951 5
ALM 400 V 89 370 178 410 76.7 2300 0.737 0.952
SLM/BLM 480 V 101 365 178 448 88.3 2650 0.765 0.95
ALM 480 V 108 370 178 498 93.3 2800 0.735 0.951
1PH8165-7□G2□
Y connection
SLM/BLM 400 V 91 435 205 369 66.7 2000 0.733 0.938 5.3
ALM 400 V 102 425 200 415 76.7 2300 0.742 0.94
SLM/BLM 480 V 112 405 196 448 88.3 2650 0.767 0.941
ALM 480 V 118 405 193 498 93.3 2800 0.744 0.942
1PH8167-5□F2□
Y connection
SLM/BLM 400 V 62 395 145 348 50 1500 0.744 0.94 0.214 4.3 283
ALM 400 V 72 395 145 405 58.3 1750 0.743 0.942
SLM/BLM 480 V 82 390 145 448 66.7 2000 0.762 0.941
ALM 480 V 91 395 145 498 73.3 2200 0.754 0.938
1PH8167-7□F2□
Y connection
SLM/BLM 400 V 78 500 178 365 50 1500 0.738 0.932 5.2
ALM 400 V 89 490 176 415 58.3 1750 0.749 0.934
SLM/BLM 480 V 98 470 173 448 66.7 2000 0.77 0.928
ALM 480 V 106 460 170 498 73.3 2200 0.764 0.93
1PH8167-5□G2□
Y connection
SLM/BLM 400 V 84 400 177 370 66.7 2000 0.776 0.952 5
ALM 400 V 95 395 177 415 76.7 2300 0.78 0.949
SLM/BLM 480 V 103 370 177 448 88.3 2650 0.785 0.95
ALM 480 V 114 390 177 498 93.3 2800 0.781 0.951
1PH8167-7□G2□
Y connection
SLM/BLM 400 V 96 460 202 370 66.7 2000 0.777 0.939 5.3
ALM 400 V 106 440 197 415 76.7 2300 0.779 0.94
SLM/BLM 480 V 110 400 191 448 88.3 2650 0.78 0.941
ALM 480 V 121 415 188 498 93.3 2800 0.781 0.942
Technical data and characteristics
2.1Technical speci󹪝cations
Technical speci󹪝cations and characteristics SIMOTICS M-1PH8 reluctance motors
12 Con󹪝guration Manual, 12/2022, A5E51895871
