2.1.3 Shaft height 132 – water cooled
Table 2-4 1PH8 shaft height 132, water cooling (basic data)
Motor type Supply voltage P
rated
kW
M
rated
Nm
I
rated
A
U
rated
V
f
rated
Hz
n
rated
r/min
cos Φ η

J
kgm
2
P_cool
kW
m
kg
1PH8138-5□F2□
Y connection
SLM/BLM 400 V 32 205 84 315 50 1500 0.748 0.928 0.093 3.4 163
ALM 400 V 37 205 84 366 58.3 1750 0.747 0.931
SLM/BLM 480 V 42.5 205 84 417 66.7 2000 0.745 0.931
ALM 480 V 46.5 200 84 458 73.3 1750 0.744 0.932
1PH8138-7□F2□
Y connection
SLM/BLM 400 V 40 255 102 330 50 1500 0.743 0.919 3.8
ALM 400 V 45.5 250 100 381 58.3 1750 0.741 0.922
SLM/BLM 480 V 51 240 98 432 66.7 2000 0.741 0.922
ALM 480 V 54 235 96 472 73.3 1750 0.74 0.923
1PH8138-5□G2□
Y connection
SLM/BLM 400 V 50 240 125 333 66.7 2000 0.741 0.934 4.4
ALM 400 V 57 240 125 382 76.7 2300 0.74 0.936
SLM/BLM 480 V 66 240 125 439 88.3 2650 0.739 0.938
ALM 480 V 70 240 125 463 93.3 2800 0.738 0.939
1PH8138-7□G2□
Y connection
SLM/BLM 400 V 63 300 153 350 66.7 2000 0.731 0.926 5.5
ALM 400 V 71 295 151 399 76.7 2300 0.73 0.928
SLM/BLM 480 V 80 290 148 448 88.3 2650 0.742 0.93
ALM 480 V 83 285 146 481 93.3 2800 0.73 0.931
Technical data and characteristics
2.1Technical speci󹪝cations
Technical speci󹪝cations and characteristics SIMOTICS M-1PH8 reluctance motors
Con󹪝guration Manual, 12/2022, A5E51895871 11
