Siemens SIMOTICS M-1PH8 Manual

Motor type Supply voltage P
rated
kW
M
rated
Nm
I
rated
A
U
rated
V
f
rated
Hz
n
rated
r/min
cos Φ η

J
kgm
2
m
kg
1PH8167-5□D□□
Y connection
SLM/BLM 400 V 39 370 96 335 33.3 1000 0.751 0.925 0.214 244
ALM 400 V 45 370 96 383 38.3 1150 0.748 0.929
SLM/BLM 480 V 52 370 96 448 45 1350 0.747 0.937
ALM 480 V 58 370 96 498 50 1500 0.745 0.939
1PH8167-7□D□□
Y connection
SLM/BLM 400 V 44 420 106 342 33.3 1000 0.751 0.917
ALM 400 V 49 410 104 390 38.3 1150 0.749 0.92
SLM/BLM 480 V 56 395 101 448 45 1350 0.755 0.926
ALM 480 V 60 385 99 498 50 1500 0.749 0.927
1PH8167-5□F□□
Y connection
SLM/BLM 400 V 56 355 132 345 50 1500 0.74 0.951
ALM 400 V 65 355 132 402 58.3 1750 0.74 0.952
SLM/BLM 480 V 74 355 132 448 66.7 2000 0.756 0.95
ALM 480 V 82 355 132 498 73.3 2200 0.749 0.951
1PH8167-7□F□□
Y connection
SLM/BLM 400 V 63 400 146 352 50 1500 0.74 0.940
ALM 400 V 71 385 141 408 58.3 1750 0.74 0.942
SLM/BLM 480 V 78 370 137 448 66.7 2000 0.761 0.941
ALM 480 V 82 355 132 498 73.3 2200 0.749 0.941
1PH8167-5□G□□
Y connection
SLM/BLM 400 V 68 325 145 370 66.7 2000 0.767 0.959
ALM 400 V 78 320 145 415 76.7 2300 0.774 0.96
SLM/BLM 480 V 85 305 145 448 88.3 2650 0.785 0.961
ALM 480 V 94 320 145 498 93.3 2800 0.776 0.959
1PH8167-7□G□□
Y connection
SLM/BLM 400 V 81 390 170 370 66.7 2000 0.777 0.951
ALM 400 V 89 370 165 415 76.7 2300 0.78 0.952
SLM/BLM 480 V 94 335 159 448 88.3 2650 0.785 0.949
ALM 480 V 101 345 155 498 93.3 2800 0.779 0.95
Technical data and characteristics
2.1Technical speci󹪝cations
Technical speci󹪝cations and characteristics SIMOTICS M-1PH8 reluctance motors
10 Con󹪝guration Manual, 12/2022, A5E51895871
