2.1.2 Shaft height 160 – forced ventilation
Table 2-3 1PH8 shaft height 160, forced ventilation (basic data)
Motor type Supply voltage P
rated
kW
M
rated
Nm
I
rated
A
U
rated
V
f
rated
Hz
n
rated
r/min
cos Φ η

J
kgm
2
m
kg
1PH8165-5□D□□
Y connection
SLM/BLM 400 V 35 335 97 298 33.3 1000 0.749 0.923 0.183 221
ALM 400 V 40 335 97 342 38.3 1150 0.747 0.926
SLM/BLM 480 V 47 335 97 400 45 1350 0.745 0.935
ALM 480 V 52 335 97 443 50 1500 0.743 0.937
1PH8165-7□D□□
Y connection
SLM/BLM 400 V 39 370 106 304 33.3 1000 0.749 0.914
ALM 400 V 43.5 365 104 347 38.3 1150 0.747 0.917
SLM/BLM 480 V 49.5 350 101 404 45 1350 0.745 0.923
ALM 480 V 53.5 340 99 445 50 1500 0.743 0.925
1PH8165-5□F□□
Y connection
SLM/BLM 400 V 45 285 107 344 50 1500 0.743 0.948
ALM 400 V 52 285 107 401 58.3 1750 0.741 0.95
SLM/BLM 480 V 60 285 107 448 66.7 2000 0.753 0.947
ALM 480 V 66 285 107 498 73.3 2200 0.745 0.949
1PH8165-7□F□□
Y connection
SLM/BLM 400 V 56 355 128 359 50 1500 0.744 0.938
ALM 400 V 63 345 124 415 58.3 1750 0.742 0.94
SLM/BLM 480 V 68 325 120 448 66.7 2000 0.766 0.939
ALM 480 V 73 315 117 498 73.3 2200 0.757 0.94
1PH8165-5□G□□
Y connection
SLM/BLM 400 V 51 245 110 370 66.7 2000 0.765 0.956
ALM 400 V 58 245 110 415 76.7 2300 0.771 0.957
SLM/BLM 480 V 64 230 110 448 88.3 2650 0.782 0.958
ALM 480 V 70 240 110 498 93.3 2800 0.773 0.959
1PH8165-7□G□□
Y connection
SLM/BLM 400 V 68 325 143 370 66.7 2000 0.781 0.949
ALM 400 V 74 310 138 415 76.7 2300 0.782 0.95
SLM/BLM 480 V 77 275 132 448 88.3 2650 0.785 0.951
ALM 480 V 82 280 128 498 93.3 2800 0.781 0.951
