2.1.1 Shaft height 132 – forced ventilation
Table 2-2 1PH8 shaft height 132, forced ventilation (basic data)
Motor type Supply voltage P
rated
kW
M
rated
Nm
I
rated
A
U
rated
V
f
rated
Hz
n
rated
r/min
cos Φ η

J
kgm
2
m
kg
1PH8138-5□D□□
Y connection
SLM/BLM 400 V 21 200 62 283 33.3 1000 0.759 0.910 0.093 145
ALM 400 V 24 200 62 324 38.3 1150 0.757 0.913
SLM/BLM 480 V 28.5 200 62 378 45 1350 0.754 0.926
ALM 480 V 31.5 200 62 419 50 1500 0.752 0.928
1PH8138-7□D□□
Y connection
SLM/BLM 400 V 25 240 72 292 33.3 1000 0.76 0.901
ALM 400 V 28.5 240 71 334 38.3 1150 0.757 0.905
SLM/BLM 480 V 33 235 70 389 45 1350 0.754 0.915
ALM 480 V 36 230 70 429 50 1500 0.752 0.917
1PH8138-5□F□□
Y connection
SLM/BLM 400 V 32 205 75 350 50 1500 0.752 0.928
ALM 400 V 37 205 75 406 58.3 1750 0.75 0.931
SLM/BLM 480 V 42 200 75 448 66.7 2000 0.768 0.931
ALM 480 V 46.5 200 75 498 73.3 2200 0.761 0.932
1PH8138-7□F□□
Y connection
SLM/BLM 400 V 38 240 87 361 50 1500 0.752 0.918
ALM 400 V 43.5 235 85 415 58.3 1750 0.754 0.921
SLM/BLM 480 V 47 225 83 448 66.7 2000 0.777 0.92
ALM 480 V 51 220 81 498 73.3 2200 0.769 0.922
1PH8138-5□G□□
Y connection
SLM/BLM 400 V 43 205 95 370 66.7 2000 0.752 0.943
ALM 400 V 49.5 205 95 415 76.7 2300 0.764 0.945
SLM/BLM 480 V 55 198 95 448 88.3 2650 0.783 0.946
ALM 480 V 60 205 95 498 93.3 2800 0.766 0.947
1PH8138-7□G□□
Y connection
SLM/BLM 400 V 48 230 104 370 66.7 2000 0.764 0.933
ALM 400 V 54 220 102 415 76.7 2300 0.77 0.935
SLM/BLM 480 V 57 205 99 448 88.3 2650 0.784 0.936
ALM 480 V 61 210 97 498 93.3 2800 0.768 0.937
Technical data and characteristics
2.1Technical speci󹪝cations
Technical speci󹪝cations and characteristics SIMOTICS M-1PH8 reluctance motors
8 Con󹪝guration Manual, 12/2022, A5E51895871
