Description
1.4 Representation of SIMOTION D425-2 DP and D435-2 DP
SIMOTION D4x5-2
Manual, 02/2012
23
CAUTION
SIMOTION D425-2 DP and D435-2 DP must be operated with a double fan/battery module
for heat dissipation. Without this module, the Control Units will not start up and cannot be
commissioned.
Information on how to install the double fan/battery module can be found in "Supplementary
system components", in Section Installing the fan/battery module (Page 95).
Note
SIMOTION D425-2 DP and D435-2 DP are supplied with pre-assembled spacers. They can
be removed if necessary.
For further details, see the
SIMOTION D4x5-2
Commissioning and Hardware Installation
Manual.
