Technical data of the D4x5-2
4.4 Power supply
SIMOTION D4x5-2
78 Manual, 02/2012
4.4 Power supply
External 24 V power supply
The control unit is supplied by an external 24 V power supply (e.g. SITOP).
The tolerance range for the input voltage of the SIMOTION D4x5-2 is between 20.4 and
28.8 VDC.
Table 4- 5 Power supply data
D425-2 DP
D435-2 DP
D425-2 DP/PN
D435-2 DP/PN
D445-2 DP/PN
D455-2 DP/PN
Power supply
• Rated value
• Permissible range
Safety extra-low voltage DVC A (PELV)
24 VDC
(20.4 ... 28.8 V)
Current consumption, typically
1)
0.7 A 1.0 A 1.9 A
Starting current, typically
1)
5 A 5 A 5 A
Power loss, typically
1)
17 W 24 W 46 W
1)
With no load on inputs/outputs, no 24 V supply via DRIVE-CLiQ and PROFIBUS interfaces
Table 4- 6 Input voltage specification
Input voltage D4x5-2
Minimum input voltage 20.4 V
Nominal input voltage 24 V
Maximum input voltage 28.8 V
Table 4- 7 Specification of the input current - typical current consumption
Typical current consumption
1)
Device type D425-2 DP
D435-2 DP
D425-2 DP/PN
D435-2 DP/PN
D445-2 DP/PN
D455-2 DP/PN
Minimum input voltage 0.8 A 1.2 A 2.24 A
Nominal input voltage 0.7 A 1.0 A 1.9 A
Maximum input voltage 0.6 A 0.8 A 1.58 A
1)
With no load on inputs/outputs and no 24 V supply via DRIVE-CLiQ or PROFIBUS interface
