Description
1.6 Representation of SIMOTION D445-2 DP/PN and D455-2 DP/PN
SIMOTION D4x5-2
Manual, 02/2012
27
CAUTION
SIMOTION D445-2 DP/PN and D455-2 DP/PN must be operated with a double fan / battery
module for heat dissipation. Without this module, the control units will not start up and
cannot be commissioned.
Information on how to install the double fan / battery module can be found in "Supplementary
system components", in Section Installing the fan/battery module (Page 95).
Note
With the D445-2 DP/PN and D455-2 DP/PN, the spacers can only be removed with the
"external air cooling" installation method. In this installation method, the cooling fins are
inserted through a cutout in the rear cabinet panel.
For further details, see the
SIMOTION D4x5-2
Commissioning and Hardware Installation
Manual.
