Note
The 24 V supply voltage is looped through via the 24 V connector. In this case, pin 1 is
jumpered
with pin 2, and pin 3 is jumpered with pin 4 in the connector. The maximum current
can be limited through the current carrying capacity of the cable. The current carrying capacity
of the cable depends, for example, on the type of cable installation (cable duct, laying on a
cable rack, etc.)
Note
The power supply terminal strip must be screwed on tightly using a flat-bladed screwdriver.
7.5.2.6 Measuring sockets
Application
The T0, T1 and T2 measuring sockets are used to output analog signals. Any signal
interconnectable via SINAMICS can be output on any measuring socket of the CX32‑2.
Note
The measuring sockets should be used exclusively for servicing purposes.
The measurements may only be performed by appropriately trained specialists.
The
measuring sockets are suited for multiple-spring wire connectors with a diameter of 2 mm.
7.5.3 Displays of the LEDs
Description
Table 7-27
CX32‑2 LEDs
LED Description
RDY Operating modes of the CX32‑2
DP Status of the communication connection between the D4x5‑2 and the CX32‑2
Additional references
Detailed information on the states of the status LEDs can be found in the
SIMOTION D4x5‑2
Commissioning and Hardware Installation Manual, Section
Diagnostics
.
Supplementary system components
7.5 CX32-2 controller extension
SIMOTION D4x5-2
Manual, 04/2014 125
