Note
The
information contained in each field of the type plate on your actual control unit may differ
from that presented in this manual (for example, a later product version, approvals and marks
that have not yet been granted, e.g. C-Tick, etc.).
MAC addresses
A
second type plate for the MAC addresses of the Ethernet interfaces and the PROFINET IO
interface is attached to the front of the device. You see this type plate when you open the front
cover of the control unit.
0$&DGGUHVV;
0$&DGGUHVVRI;
0$&DGGUHVVRI;
+DUGZDUHUHYLVLRQOHYHO
6HULDOQXPEHU
'DWDPDWUL[FRGH
0RGXOHGHVLJQDWLRQ
2UGHU1R
Figure 2-6 SIMOTION D4x5-2 DP/PN MAC addresses
Note
For
SIMOTION D4x5-2 DP, the MAC address for the X120 interface is printed instead of the
MAC address for the X150 interface.
Description
2.7 Type plates
SIMOTION D4x5-2
Manual, 04/2014 37
