Service selector switch
The following table shows the possible positions of the service selector switch. The service
selector switch positions are explained in the order in which they are arranged on the
SIMOTION D4x5‑2.
Table 3-3
Switch positions of the service selector switch
Service mode Switch position Meaning
- 0 No service/diagnostic functions activated (default setting)
Delete/restore
non-volatile
SIMOTION data
1
or
A → 1
When the "Delete/restore non-volatile SIMOTION data" switch
setting is selected, the non-volatile data of the D4x5‑2 is first
deleted and then restored along with the contents of the
PMEMORY backup file.
Position "1": The data backed up with the system function
_savePersistentMemoryData are preferably
restored
Position
"A" → "1":
(as of V4.4)
The data backed up by service selector switch
position
"D" / web server / DIAG pushbutton are
preferably restored
Web server in
Security Level
Low
8 Switches the SIMOTION IT web server to Security Level Low,
if the user database is empty.
You will find detailed information in the
SIMOTION IT
Diagnostics and Configuration
Diagnostics Manual.
Downgrade
(device update
tool)
B SIMOTION D4x5‑2 control units and projects can be upgraded
using upgrade data created at an earlier point in time. This
upgrade
data are generated with the device update tool (Menu:
"Project>Start device update tool" in SIMOTION SCOUT).
If the upgrade process fails to bring about the desired result,
the upgrade can be rejected by means of the switch position.
This will roll the system back to the previous configuration.
Backup of
diagnostic data
and non-volatile
SIMOTION data
D The diagnostic data and non-volatile SIMOTION data can be
backed up in STOP, STOPU, and RUN state. The advantage
of backing up in RUN state is the availability of enhanced
diagnostic information (via HTML pages) and TO alarm
information.
Note
Alternatively,
diagnostic data and non-volatile SIMOTION data can also be backed up via the
DIAG button, see Section DIAG button (Page 48).
Operator control (hardware)
3.2 Operator controls
SIMOTION D4x5-2
Manual, 04/2014 47
