Commissioning (software)
6.22 Migration of SIMOTION D4x5 to SIMOTION D4x5-2
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, 02/2012
307
CBE30-2
The tables below provide an overview of the possible combinations:
Table 6- 22 Communication board Ethernet combinations
Communication
board Ethernet
Order number Use in D4x5 Use in D4x5-2
CBE30 6FC5312-0FA00-0AA0 Possible Not possible
CBE30-2 6FC5312-0FA00-2AA0 Not possible
• D4x5-2 DP/PN: As of V4.3
• D4x5-2 DP: Not possible
Only approved combinations can be configured. If physically an incorrect Ethernet
communication board is used, the CBE cannot be fully inserted into the option slot.
CompactFlash card
A CompactFlash card with D4x5 firmware / drive software cannot run on a D4x5-2. The
same applies for the reverse situation.
In case of an error, the six LED displays (RUN to DP/MPI) flash yellow at 2 Hz. An entry is
also made in the diagnostic buffer.
Licenses
Licenses purchased for SIMOTION D can be used for both the D4x5 and D4x5-2.
Previously used platform-specific "MultiAxes Package for D445/D445-1" licenses can also be
used for the D445-2 DP/PN and D455-2 DP/PN.
A new license has not been introduced for the D455-2 DP/PN performance class.
