Installing

2.3 Installing supplementary system components

SIMOTION D4x5-2

Commissioning and Hardware Installation Manual, 02/2012

The CX32-2 can now be mounted directly on a mounting surface, e.g. a wall of the control

cabinet. It is fastened with two screws M6 / 6 Nm.

6HFXUHZLWK

VFUHZV01P

Figure 2-10 Mounting the CX32-2 on a mounting surface
