Siemens SINAMICS DCM Hardware Installation Manual

Description
Mounting kit to increase the degree of protection to IP20
Hardware Installation Manual, 02/2021, A5E34871844B
11
Table 2- 1 Units with armature current from 15 to 30 A (frame size A)
Connection
Cable diameter
1U1, 1V1, 1W1 (line connection)
Ø 0.0 mm ... Ø 10.0 mm
1C1, 1D1 (armature connection)
Ø 0.0 mm ... Ø 10.0 mm
Protective conductor
Ø 0.0 mm ... Ø 7.0 mm
Table 2- 2 Units with armature current from 60 to 280 A (frame size B)
Connection
Cable diameter, Set 1
Cable diameter, Set 2
1U1, 1V1, 1W1 (line connection)
Ø 0.0 mm ... Ø 16.0 mm
Ø 16.0 mm ... Ø 21.0 mm
1C1, 1D1 (armature connection)
Ø 0.0 mm ... Ø 16.0 mm
Ø 16.0 mm ... Ø 21.0 mm
Protective conductor
Ø 0.0 mm ... Ø 13.0 mm
Ø 14.0 mm ... Ø 17.0 mm
Table 2- 3 Units with armature current from 400 to 600 A (frame size C)
Connection
Cable diameter, Set 1
Cable diameter, Set 2
1U1, 1V1, 1W1 (line connection)
Ø 15.0 mm ... Ø 19.0 mm
Ø 19.0 mm ... Ø 23.0 mm
1C1, 1D1 (armature connection)
Ø 18.0 mm ... Ø 21.0 mm
Ø 22.0 mm ... Ø 26.0 mm
Protective conductor
Ø 15.0 mm ... Ø 19.0 mm
Ø 17.0 mm ... Ø 22.5 mm
Table 2- 4 Units with armature current from 720 to 850 A (frame size D)
Connection
Cable diameter, Set 1
Cable diameter, Set 2
1U1, 1V1, 1W1 (line connection)
Ø 15.0 mm ... Ø 19.5 mm
Ø 20.0 mm ... Ø 24.0 mm
1C1, 1D1 (armature connection)
Ø 15.0 mm ... Ø 19.5 mm
Ø 20.0 mm ... Ø 24.0 mm
Protective conductor
Ø 15.0 mm ... Ø 20.0 mm
Ø 16.0 mm ... Ø 21.5 mm
