6
174
174
see detail A
see detail A
Pos 174 snap in
from the outside
detail A
1:1
9
11
109
3Nm
109
3Nm
109
3Nm
109
3Nm
sheet 2 of 13
Mounting Instructions IP20
case size A, 15A-30A
