Technical data
83
SINAMICS V50 converter
Operating Instructions, 04/2022, FW V1.0, A5E44777205B AB
SINAMICS V50 dimensions
Frame size
Dimensions (mm)
Drilling
dimensions
(mm)
Mounting
Clearances to other
devices (mm)
B T H b h
Screws/torque
(Nm)
Top Bottom Lateral
FSD 275 200 450 200 430 4 x M8/13 300 300 50
FSE 325 248 560 240 540 4 x M8/13 300 300 50
FSF 385 248 665 240 645 4 x M8/13 300 300 50
FSG 465 355 750 380 720 4 x M8/13 350 350 50
FSH 550 385 900 440 868 4 x M8/13 350 350 50
SINAMICS V50 wire connections
Frame size
Power connections
(R, S, T, P1, PB, (+), (-), U, V, W)
Grounding terminal
(PE)
Terminal
screw
Tightening
torque
(Nm)
Wire
spec.
(mm
2
)
Terminal
screw
Tightening
torque (Nm)
Wire spec.
(mm
2
)
FSD M6 4-6 25 M6 4-6 16
FSE M8 10 12 35 M8 10-12 16
FSF M10 20 25 60 M8 10-12 35
FSG M12 40-45 150 M10 20-25 75
FSH M12 40-45 150x2 M10 20-25 75x2
