Technical data
9
Siemens Building Technologies
EN
Fire Safety & Security Products 01.2009
3 Technical data
Video
Signal format PAL or NTSC (auto-detect)
Video input Composite: 4 looping inputs, 1 Vpp auto-terminating, 75 Ohms
Monitor outputs Composite: 1 BNC, 1 Vpp, 75 Ohms
VGA: 1 (auto-detect)
Video resolution Composite: 720 x 576 (PAL), 720 x 480 (NTSC)
VGA: 720x576 @ 75 Hz (PAL), 720x480 @ 60 Hz (NTSC)
Playback/record speed
(images per second)
100 ips (PAL), 120 ips (NTSC)
Inputs / Outputs
Alarm input 4 TTL, programmable as NC or NO, 4.3 V threshold
Alarm output 1 relay output, terminal blocks, programmable as NC or NO,
2 A @ 125 V AC, 1 A @ 30 V DC
Alarm reset input 1x TTL, terminal block
Internal buzzer 80 dB @ 10 cm
Network connectivity 10/100 Mbps Ethernet (RJ-45)
Connections
Video input Composite: 4 BNC
Video loop Composite: 4 BNC (auto-terminating)
Monitor output Composite: 1 BNC
VGA: 1 VGA
Alarm input/output Terminal blocks
Ethernet port RJ-45
RS-232C serial port DB9 (P)
RS-485 serial port 2-connector terminal block
USB port 1 (USB 2.0)
IR port 1 remote control
Storage
Primary storage SATA hard disk drive
Secondary storage (optional) USB hard-disk drive, USB CD-RW drive or USB flash drive
Environmental
Operating temperature 5 – 40 °C (41 – 104 °F)
Operating humidity 0 – 90 %
Power supply
Power 100 - 240 V AC, 0.8 – 0.4 A, 60/50 Hz
Power consumption 30 W max.
General
Dimensions (WxHxD) 340 x 46.5 x 310 mm (13.4" x 1.8" x 12.2")
Unit weight 3.0 kg (6.6 lbs)
Shipping weight 4.5 kg (9.9 lbs)
Shipping dimensions (WxHxD) 440 x 143 x 410 mm (17.3" x 5.6" x 16.1")
Specifications are subject to change without notice.
