Siemens SKP25 Series User Manual

)
SKP25U.. Pressure Regulating Gas Valve Actuators Technical Instructions
Document Number 155-752
July 9, 2014
Information in this publication is based on current specifications. The company reserves the right to make changes in specifications and models as
d
esign improvements are introduced. Other product or company names mentioned herein may be the trademarks of their respective owners.
© 2005 Siemens Building Technologies, Inc.
SCC
Inc.
1250 Lunt Avenue
Elk Grove Village, IL 60007
U.S.A.
Your feedback is important to us. If you
have comments about this document,
please send them to
techsupport@SCCcombustion.com
Document No. 155-752
Country of Origin: US
Page 7
Service
Terminal
Designations
There are no serviceable parts on the SKP25 series actuators. If inoperative, replace
the actuator. Tag wires before servicing.
GAS0049R1
SKP25.012U.. SKP25.011U.. SKP25.013U..
Figure 2. Terminal Designations.
Dimensions
GAS0052R1
3.20
(81)
2.16
(55)
PRESSURE
TEST PORT
0.35" (8.5) O.D.
6.61
(168)
3.82
(97)
1.30
(33)
1.02
(26)
3.78
(96)
1/2"-14
NPSM
1/4"-18 NPT
FEMALE
1.41
(36)
3.15
(80)
7.95
(202)
1/4"
FEMALE
3.39 SQUARE
(86)
7.87
(200)
8.70
(221)
Figure 3. SKP25U.. Dimensions in Inches, Millimeters in Parentheses.
