Features en
25
2. Set the slider to ON or OFF.
3. Push in the top basket.
Cleaning glassZone
Limescale and soiling from the dish-
washing water can block the nozzles.
Note:Always operate the appliance
with the glassZone fitted.
1. Pull out the top basket.
2. Pull the tab on the glassZone up
and forwards .
3. Set the slider to ON.
4. Clean under running water.
5. Place the glassZone in the top
basket and lock in position .
Check that the mounts are in the
correct position.
a The glassZone audibly clicks into
position .
6. Push in the top basket.
Basket heights
Set the baskets at the right height.
Appliance height 81.5cm with cutlery drawer
Setting Top basket Bottom basket
1 max. ø 16 cm 31 cm
2 max. ø 18.5 cm 27.5 cm
3 max. ø 21 cm 25 cm
