Building Technologies Electromotoric Actuators CA1N4505en
HVAC Products 26.10.2006
Technical data
SQL35.00 SQL85.00 SQL36E50… SQL36E65 SQL36E110 SQL36E160
Power supply Operating voltage AC 230 V
±15 %
AC 24 V
±20 %
AC 230 V
–5 / +10 %
Frequency 50 / 60 Hz
Power consumption
1)
6.5 VA 35 VA 160 VA 235 VA
Control Positioning signal 3-position
Parallel operation parallel operation of several actuators not possible
Operating data Positioning time for 90°
at 50 Hz
at 60 Hz
125 s
105 s
25 s
20 s
6 s
2)
5 s
12 s
2)
10 s
24 s
2)
20 s
Angle of rotation 90° ± 1° (factory setting)
Torque
1)
20 Nm 40 Nm 100 Nm 400 Nm 1200 Nm
End switch Switching capacity AC 250 V, 3 A resistive, 1.5 A inductive
Switching differential approx. 1°
Heating element AC 230 V, 5 W
Medium temperature Permissible temperature of medium in the assembled valve: 120°C
Standards Meets the requirements for
CE marking in
EMC directive 89/336/EEC
Low-voltage directive 73/23/EEC
Electromagnetic
compatibility
AC emissions: EN 61000-3-ff, EN 55014-1 and EN 55022
AC + DC immunity: EN 61000-4-ff
Product standards for
automatic electrical controls
EN 60730-2-14 DIN EN 61010
C-tick N474
Housing protection
standard
IP 44 to IEC 60529 IP 67 to IEC 60529
Protection class III or II to EN 60730
EN ISO 5211 32mm Flanges and shaft
connection to actuator F04 / F05 F07 F10 F12 / F16
Dimensions / weight Dimensions see «Dimensions»
Cable glands 4 x ∅ 20,5 mm (for M20) 2 x M20
Weight 1.4 kg 4.5 kg 7 kg 14 kg 25 kg
Materials Housing base, yoke die-cast aluminium
Cover plastic die-cast aluminium
1)
These values apply at nominal voltage, at an ambient temperature of 20 °C and at the specified nominal
running time
2)
Variable positioning time with SEZ31.1 auxiliary module (see below)
Accessories for SQL35.00 / 85.00 Weight
• Double auxiliary switch
ASC9.5 / ASC9.4
Switching capacity
Switching differential
AC 250 V, 10 A resistive, 3 A inductive
approx. 1°
ASC9.4 85 g
ASC9.5 30 g
• Auxiliary switch with
potentiometer ASZ7.4
Switching capacity
Switching differential
Change in resistance
AC 250 V, 10 A resistive, 3 A inductive
approx. 1°
0 ...1000 Ω corresponding to 0 ... 90 °
60 g
Accessories for SQL36E… Weight
• Double auxiliary switch
ASC36
Switching capacity
Switching differential
AC 250 V, 3 A resistive, 1.5 A inductive
approx. 1°
60 g
• Potentiometer ASZ36 Change in resistance 0...1000 Ω corresponding to 0...90° 50 g
• Auxiliary module
SEZ31.1
Positioning time for 90 °
at 50 Hz
SQL36E65: 30...180 s
SQL36E110: 60…360 s
SQL36E160: 120…720 s
60 g
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
