Type summary
Type reference Drive shaft
1)
no.
Running time
(min.)
for 90°
s
Nominal
torque
(max.)
Nm
Holding
torque
2)
(max.)
Nm
Radial
bearing
force (max.)
N
SQM45.291A9
110 3
3)
1.5 190
SQM45.295A9
510 3
3)
1.5 190
SQM48.497A9
7 30 20
4)
20 420
SQM48.697A9
7 60 35
4)
35 800
1) Refer to «Dimensions» 4) Under nominal conditions. Under extreme conditions
2) With operating voltage applied (above +50 °C ambient temperature), the torque is about
3) Under nominal conditions. Under extreme conditions
(below –15 °C ambient temperature), the available torque
is about 15 % lower
15 % lower
Ordering
When ordering, please give type references of actuator and accessories according to
«Type summary».
In addition to the actuator, the following item is to be ordered separately and is also
supplied as a separate item:
· Shielded cable
· Special terminals RAST3.5 as part of the AGG5.720 / AGG5.721 set
Accessories
Accessories must be ordered as separate items.
Adapter for gas valves VKF41...C ASK33.4
Connecting cables AGG5.6...
- Only the specified cables may be used!
- Refer to Basic Documentation P7550
Actuators SQM4...
