Siemens SQM5 User Manual

Technical Instructions SQM5… Reversing Actuators
Document No. 155-517P25
July 9, 2007
Page 4 Siemens Building Technologies, Inc.
Product Numbers
Table 1. Product Numbers for Pre-assembled Actuators.
Torque
1
Running
Time
2
[lb-in] 90°@ 60
Hzsec
Line
Voltage
4-20 mA
0-135
Ω
0-10 Vdc
110 V 220 V 24 V
90 8 ccw x x SQM50.261R1G3
90 8 cw x x SQM50.261R1G3R
90 8 ccw x SQM50.264R1A SQM50.264R2A
90 8 cw x SQM50.264R1A0R
90 8 ccw x SQM50.264R1A3
90 8 cw x x SQM50.264R1G3R
90 8 ccw x x SQM50.264R1G4
140 12 ccw x x SQM50.361R1G3
140 12 cw x x SQM50.361R1G3R
140 12 ccw x x SQM50.361R1G7
140 12 ccw x x SQM50.364R1G3
140 12 cw x x SQM50.364R1G3R
140 25 ccw x SQM50.461R1A
140 25 ccw x SQM50.461R1A3
140 25 ccw x x SQM50.461R1G3
140 25 cw x x SQM50.461R1G3R
140 25 ccw x x SQM50.461R1H3
140 25 ccw x x x x SQM50.461R1Z3
140 25 ccw x x x x SQM50.461R1Z7
140 25 ccw x SQM50.464R1A SQM50.464R8A
140 25 cw x SQM50.464R1A0R
140 25 ccw x SQM50.464R1A3
140 25 cw x SQM50.464R1A3R
140 25 ccw x x SQM50.464R1G3 SQM50.464R8G3
140 25 cw x x SQM50.464R1G3R SQM50.464R2G3R
140 25 ccw x x SQM50.464R1G7
140 25 cw x x SQM50.464R1G7R
140 25 ccw x x SQM50.464R1H3 SQM50.464R8H3
140 25 ccw x x x x SQM50.464R1Z3 SQM50.464R2Z3 SQM50.464R8Z3
200 25 ccw x SQM53.464R1A
200 25 ccw x SQM53.464R1A3
200 25 ccw x x SQM53.464R1G3
200 25 ccw x x SQM53.464R1G7
200 25 cw x x SQM53.464R1G7R
200 25 ccw x x x x SQM53.464R1Z3 SQM53.464R2Z3
200 25 ccw x x x x SQM53.467R1Z3
200 25 cw x x x x SQM53.467R1Z3R
200 25 ccw x SQM53.467R2A3
310 37 ccw x SQM56.564R1A
310 37 ccw x x SQM56.564R1G4
310 37 ccw x x SQM56.564R1G7
310 37 ccw x x SQM56.564R1H4
310 37 ccw x x x x SQM56.564R1Z3
400 50 ccw x x SQM56.664R1G3
400 50 ccw x x x x SQM56.664R1Z3
400 50 cw x SQM56.667R1A3R
400 50 ccw x x SQM56.667R1G3
400 50 cw x x SQM56.667R1G7R
400 50 ccw x x x x SQM56.667R1Z3
Rotation
direction
Input Control Signals
3
Product Number
1. Torque will vary with the selection of the shaft. See Specifications.
2. Running time for 135° Æ multiply by 1.5. For 50 Hz Æ multiply by 1.2
3. SQM5x.xxxxxZx models also accept a 0 to 20 mA input signal.
