10/20
Smart Infrastructure CC1N7802en
8/11/2021
Technical data
Degree of protection IP54 in accordance with EN 60529:1991 +
A1:2000 + A2:2013 when using the cable
entry provided plus plastic washers for the
M fixing screws as shown in the
Dimensions chapter.
Please note!
The drive shaft bearing must be installed appropriately to protect
against direct exposure to water and dust, otherwise IP54 cannot be
Protection class
II according to EN 60730-1:2016 +
External primary fuse (Si) 6.3 A
T (to be installed on site) according to
Cable entry Rubber grommet for the insertion of a
single sheathed cable with a maximum
diameter of 11 mm. The opening of the
rubber grommet must be suitably adapted
to the sheath diameter of the cable. To
ensure that the rubber grommet will be
tight, the cable must be correctly laid in
this area with no openings. The rubber
grommet is included in the scope of
Cable strain relief Cable strain relief bridge with 2 fixing
Cable connection 2 plug-in spaces with connection terminals
Type CUM / manufactured by Stelvio
For the following connector types:
CUF 5-4 (plug-in space X1)
CUF 5-5 (plug-in space X2)
Recommended cross-sectional area of
stranded wire
Min. 0.5 mm² and max. 1.5 mm²
The connectors are not included in the
scope of delivery (order directly from
Ferrules Matching the cross-sectional area of the
Torque and holding torque
Pause times at change in direction of
>100 ms
