SIGLENT
SDG2000X User Manual V
Introduction of SDG2000X
The manual covers the following 3 models of SDG2000X Series
Function/Arbitrary Waveform Generators: SDG2042X, SDG2082X and
SDG2122X.
SIGLENT‘s SDG2000X is a series of dual-channel function/arbitrary waveform
generators with specifications of up to 120MHz maximum bandwidth,
1.2GSa/s sampling rate and 16-bit vertical resolution. The proprietary TrueArb
& EasyPulse techniques help to solve the weaknesses inherent in traditional
DDS generators when generating arbitrary, square and pulse waveforms.
Using these techniques the SDG2000X provides users with a variety of high
fidelity, low jitter signals in order to meet the growing requirements for a
multitude of complex applications.
Key Features
Dual-channel, 120MHz maximum bandwidth, 20Vpp maximum output
amplitude, output with 80dB dynamic range
High-performance sampling system with 1.2GSa/s sampling rate and
16-bit vertical resolution. No detail in your waveforms will be lost
Innovative TrueArb technology, based on a point-by-point architecture,
supports any 8pts~8Mpts Arb waveform with a sampling rate in range of
1μSa/s~75MSa/s
Innovative Easy Pulse technology, capable of generating lower jitter
Square or Pulse waveforms, brings a wide range and extremely high
precision in pulse width and rise/fall times adjustment
A variety of analog and digital modulation types: AM、DSB-AM、FM、PM、
FSK、ASK 、PSK and PWM
Sweep and Burst functions
