SIGLENT SDG2122X Quick Start

7-SDG2000X Quick Start
Utility ----Utility Functions and System Settings
This key is used to set system parameters and check version information.
•
Press this key and then press the help softkey to obtain built-in help information about the product.
•
The corresponding key backlight will turn on when this function is selected.
Store/Recall ----Store and Recall
Through this key, users can store/recall the instrument’s state or arbitrary waveform data edited by users.
•
As it supports le management system, users can do general le operations.
•
In addition to the built-in nonvolatile memory (C disk), an external U-Disk (D disk) can also be used.
•
The corresponding key backlight will turn on when this function is selected.
10.Waveform Option
Waveforms ---- Sine
Provide sine waveform output which ranges from 1μHz to 100MHz.
•
The backlight of Waveforms will turn on when this function is selected.
•
“Frequency/Period”, “Amplitude/High level”, “Offset/Low level” and “Phase” of the sine waveform can be adjusted.
Waveforms ---- Square
Provide square waveform output which ranges from 1μHz to 25MHz.
The backlight of Waveforms will turn on when this function is selected.
•
“Frequency/Period”, “Amplitude/High level”, “Offset/Low level”, “Phase” and “Duty” of the square waveform can be adjusted.

SIGLENT SDG2122X Specifications

General

Brand	SIGLENT
Model	SDG2122X
Category	Inverter
Language	English
