To Set the Output Amplitude
The following steps describe how to change the amplitude to 8 Vpp.
1. Press the Amplitude/HighLevel softkey
The displayed amplitude is either the power-on value or the amplitude
previously selected. When changing the function, the same amplitude is used
if the current value is valid for the new waveform. To set the HighLevel for the
waveform, press the softkey again to switch to the HighLevel parameter.
2. Input the desired amplitude
Use the digital keypad to input the value directly, enter the value “8”.
Then press the corresponding softkey to select the desired unit. For example,
press Vpp.
