CCP 521 C-DIAS PROCESSOR MODULE
Page 28 15.03.2016
68
BACKGROUND RUNTIME
The total time for all background objects
exceed the maximum time; the time can
be configured using two system varia-
bles:
- BTRuntime: time remaining
- SWBTRuntime: pre-selected value for
the runtime counter
70
C-DIAS ERROR
An error occurred in connection with a C-
DIAS module.
Cause:
- The reason for this error
is documented in the log
file
Solution:
- Depends on the cause
72
S-DIAS ERROR
A connection error with a S-DIAS mod-
ule has occurred.
Possible causes:
- real network does not
match the project
- S-DIAS client is defective
Solution:
- analyze logfile
75
SRAM ERROR
Only EDGE CPUs
An error occurred while initializing,
reading or writing SRAM data.
Possible causes:
- - SRAM configured
incorrectly
- - SD card formatted
incorrectly
- - SD card removed
Solution:
- - evaluate log file
(Event00.log)
- - check configuration
- - format SD card as
EDGE medium with Lasal
Class 2
- - check SD card
95
USER DEFINED 0
User-definable code.
96
USER DEFINED 1
User-definable code.
97
USER DEFINED 2
User-definable code.
98
USER DEFINED 3
User-definable code.
99
USER DEFINED 4
User-definable code.
100
C_INIT
Initialization start; the configuration is
run.
