Shrinkable tube
Tension Test
Fiber holders
Magnification
Screen
Splicing Mode
Splicing record
storage
Built-in battery
Power supply
Operating
Conditions
Built-in lighting
Product protection
Splicing method
Standard 2N
3 in 1 fiber holder, SM, MM, bare fiber, pigtail,
rubber-insulated, multi fiber cable
300 for X or Y view, 150 for X or Y view
5 inch TFT color display
Normal / high precision splicing
Synchronize to the phone, the server to
cloud storage unlimited
7800 mA high-capacity lithium battery, charging time ≤ 3.5 hours,
continuous splicing and heating about 200 times
Input AC100-240V 50 / 60HZ, output DC13.5V / 4A, the current power
mode can be identified, real-time detection of battery power
Temperature -15 ~ +50 ℃, humidity: <95% RH (no condensation)
Working altitude: 0 ～ 5000m. Resist max. wind speed: ≤ 15m / s
easy for night operation
60mm、50mm、40mm、25mm
Waterproof, dust proof, shock-resistant
Fully automatic、Step by step splicing
BASIC PARAMETER
OPTICAL FIBER FUSION SPLICER
Fiber alignment
Core/cladding alignment / Manual alignment
Splicing time
5S
15S
Heating time
Control
technology
Real-time control and calibration of fusion ARC
Return loss
Better than 60DB
Cladding Diameter：80-150μm
Coating Diameter：100-1000μm
Fiber diameter
Fiber Cleave
Length
Coating less than 250µm：8-16mm
Coating less than 250-1000µm:16mm
Focus mode
Six motors Auto focus
Applicable
Fibers
SM(G.652&G.657)、MM（G.651）、DS(G.657)、
NZDS（G.655）
0.025dB（SM）、0.01dB（MM）0.04dB（DS/NZDS）
Splice Loss
Heating mode
Automatic heating（Preheating）
Software updates
Length
Boot time
Automatically update、 Update by a key
1 second
Optical Power
Meter
Visual Fault
Locator
Power:15mw,2hzflashing And Constantly
Bright Mode
Wavelength:850nm、1300nm、1310nm、1490nm、1550nm、1625nm
Measuring Range:-70 ~ +6db
Absolute Error:<0.3db(-50dbm ~ +3dbm Range)
