SM435 Preliminary Specifications | Zero Span (IQ Streaming)
32
Holdover of ±1 x 10-8 for temperature over -40°C to
65°C typical
System Noise Figure (typical) 12dB from 700MHz to 2.5GHz
15dB from 2.5GHz to 24GHz
18dB + 0.5 dB/GHz from 24GHz to 40GHz
26 dB + 2 dB/GHz above 40 GHz
IP
2
+75dBm from 100kHz to 20GHz
+50dBm from 20GHz to 24GHz
+70dBm from 24GHz to 43.5GHz
IP
3
+28dBm 100kHz to 4GHz
+23dBm 4GHz to 6GHz
+20dBm 6GHz to 43.5GHz
Sweep Speed (using Nuttall windowing)
Sweep Speed
1 THz/sec
1THz/sec
1THz/sec
160GHz/sec
18GHz/sec
RBW
1MHz
100kHz
30kHz
10kHz
1kHz
Amplitude Accuracy (+10dBm to Displayed Average Noise Level (DANL))
100kHz to 6GHz
>6GHz to 43.5GHz
RBW filter shape
± 2.0 dB
± 3.0 dB
Flat-Top windowing
+2.0 dB/-2.6dB
+3.0/-3.6dB
Nuttall windowing
