PRHM-34
Part No. 306700
TABLE OF CONTENTS Page
General Safety Instructions 2
Specifications 4
Major Components 5
Recommended Air Line Piping 6
Maintenance 8
Set-Up for Tool Operation 9
Operating Instructions 10
Tool Parts Removal, Replacement
and Adjustments 14
Tool Parts List 20
Air Motor Parts List 28
Troubleshooting 34
Tool Options 37
Declaration Of Conformity 39
Signode tools and machines are designed
and warranted to work together with
Signode strapping and seals. Use of non-
Signode strap and seals and/or
manufactured or specified replacement
parts may result in strap breakage or joint
separation while applying strapping to a
load or during normal shipping and
handling. This could result in serious
personal injury.
SPECIFICATIONS
STRAP
MODEL TYPE WIDTH THICKNESS SEALS
PRHM-34 MAGNUS,
PAINT & WAX
3/4"
(19mm)
0.025" (0.64mm) Minimum
0.031" (0.79mm) Maximum
34HOC
