SILENTRON - Made I n Italy
GENERAL NOTICES AND WARNIGS - To be respected when the application is possibile.
Read carefully before using the appliances
Installation: all installation, maintenance and/or modification of these control units and their devices must be carried out by qualified technical staff. These operations can be subject to specific
technical Standards which must be complied with. The device is envisioned to be used exclusively inside buildings protected from exposure to very high and very low temperatures as well as
tampering by children and/or persons without common sense for the purpose and effects of the Civil Code.
Electrical connections: all electrical connections, without exception, must be made perfectly fixing all wires as envisioned in order to prevent accidental disconnection and closing the
containers and protection devices correctly. It is mandatory to disconnect all electric connections exceeding 25V in DC and AC before opening the containers of functioning appliances.
External power supply: 230V CA 50 Hz - connect in compliance with country law regulations
Batteries Rechargeable accumulators and/or batteries of any type: these appliances use accumulators or batteries, which are potentially dangerous as they are pollutant, therefore
dangerous to the health of the public. Replace the accumulators and/or batteries exclusively with same models, position and connect them respecting the polarity indicated in the instructions. It
is mandatory to dispose of accumulators/waste batteries according to the Standards in force. This is also the case when the machines must be scrapped. The accumulators/batteries must be
previously removed, returning them to the appliance dealer or depositing them in the relevant containers made available by the distribution network. If liquid should escape from the batteries or
accumulators, use silicone gloves to protect the hands and prevent injury.
Liability: the manufacturer declines all liability consequent to incorrect installation and/or failure to use the devices supplied.
Warranty: the warranty is valid until the expiry written on the label inside the device in the terms envisioned by the Vienna Convention of 1980 regarding the International Sale of Goods.
Copyright: all rights relative to this manual are the property of Silentron s.p.a. It is prohibited to partially or totally reproduce the texts and imaged herein, as is the introduction into W.E.B.
network and/or public distribution with any means.
Standard conformity: more of CE declaration, the products are in compliance with EN 50131-1 - environmental class 2 - and they are declared of category I by the standard 300.220 - 1
(04/2006)
1) INTRODUCTION TO THE DIFFERENT APPLIANCES MODELS
This manual pertains to a family of similar products. The difference between them consists in whether they have some components or not as
due to this their functions differ. The descriptions that follow allow understanding the characteristics of every appliance and the relative
functions: the programming instructions and use refer to the more complete model: when using other models the non-provided functions do not
appear on the programming menu.
2) 5150 VOCALPHONE 2 way GSM+PSTN (gsm + phone net - the more complete model)
Two-way automatic telephone transmitter, complementary to the alarm systems of all the brands, operating alternatively both on PSTN fixed line
network and GSM, with the possibility of wired automatism control, handsfree communication and environmental telelistening.
Characteristics:
Power Supply: 12V CC - optional rechargeable backup battery 6V 1.2Ah - Absorption: 50 mA in stand-by, 300 mA in communication
Autonomy: over 18 hours with loaded battery, in absence of the primary supply. In this case, after sending the relative message, the GSM
module switches off in order to reduce consumption: it switches on for alarm transmissions and when the supply is back.
Telephone book: up to 63 programmable telephone numbers - 16 figures for each number – plus a programmable telephone number,
position 64, reserved to request the remaining credit of the SIM card.
Vocal Messages: direct recording on the appliance of 4 alarm messages plus an automatic message for “low battery” (n.5), plus an answer
message on call, to guide the user in the operations (n.6) – a total of 120 seconds of recording.
SMS: direct writing on the appliance of 4 alarm messages plus 7 precompiled technical SMS with automatic sending (see 8.3).
Digital protocols: the appliance operates also by Contact Id and/or Cesa Baud 200 digital protocols to the surveillance.
Association messages/numbers: every telephone number can be associated to one or more messages according to specific needs.
Wired messages control: 4 NC inputs, one for each alarm message. Two of these are bound through specific block input.
Relay output for load controls: n.2 relays activated in a bistable way and controllable via GSM network calling the operating unit.
Out of Order output: a negative warning indicating that there has been no GSM range for over 15 minutes.
Events’ Memory: the appliance registers the last 200 events, visible on the display recalling the relative program.
Access Codes: a user’s code (for function use) and an installer code is provided (for the programming) different between them.
Programming: simple and intuitive, supported by a vocal guide in real time.
3) 5152 VOCALPHONE GSM
Two-way automatic telephone transmitter, complementary to the alarm systems of all the brands, operating alternatively both on phone line and
GSM, with possibility of wired automatism controls, handsfree communication and environmental telelistening.
Characteristics like the previous one, except for the following variants:
Telephone book: up to 64 programmable telephone numbers - 16 figures for each number.
SMS: direct writing on the appliance of 4 alarm messages plus 6 precompiled technical SMS with automatic sending (see 8.3).
4) 5151 VOCALPHONE PSTN (phone net)
Two-way automatic telephone transmitter with environmental telelistening operating only on PSTN fixed line and compatible with all the
operating units.
Characteristics like the previous one, except for the following variants:
Power Supply: 12V CC – rechargeable optional backup battery 6V 1.2Ah - Absorption: 10 mA in stand-by, 150 mA in communication
Autonomy: around 100 hours with charged battery, in absence of the primary supply.
SMS: none
Relay output for load control: none
5) 5590 VOCALPHONE 2wayR - wireless PSTN (phone net) + GSM (no-wire model supplied with its own battery power supply)
Two-way automatic telephone transmitter operating both on PSTN fixed line and GSM line with possibility of radio automatism control,
handsfree communication and environmental telelistening. The appliance is controlled by any model of Silentron radio transmitters.
Characteristics as 5150, except for the following variants:
Power Supply: 6V CC by means of a 4-pack alkaline batteries size D - Absorption: 220 µA in stand-by, 300 mA in communication
Autonomy: around 2 years with 10 calls per year
Vocal Messages: direct recording on the appliance of 4 alarm messages plus one precompiled automatic for “flat internal battery”
A total of 120 second of recording.
SMS: direct writing on the appliance of 4 alarm messages plus 6 precompiled technical SMS with automatic sending (see 8.3).
Messages control via radio: 99 transmitters freely assignable on 4 alarm messages.
Relay output for load control: none
6) APPLIANCES OPERATION - INFORMATION FOR THE USER
Holding into account that some models do not contemplate all the functions as described above, the appliances operate as follows:
