Silver King SKBF1 - Front View (Skbr1 G)

- 4 -
1. FEATURE CHART
1-3. FRONT VIEW : SKBR1G
Ballon SKBR1G Description
1 34373 Top Frame Assembly
2 27264 Silver King Decal
3 35069 Switch-Power
4 N/A Relay, Power
5 34375 Main PCB
6 34379 Switch-Door
7
34377 Display PCB
35070 Display Inlay-Refrigerator
Ballon SKBR1G Description
8 34376 Control Board Housing
9 34382 Lock W/Keys
10
34905 Door
34390 Gasket-Glass Door
11 10327-39 Hinge Kit
12 34385 Grill Bottom
13 34325 Caster Kit
14 35076 Drain Pan Assy
