Silvercrest LT 1510 - Connecting External Equipment with SCART (Euro AV) connector; Connecting External Equipment with AV Output

13
Connecting the Devices
EN
Connecting External Equipment with SCART (Euro AV) connector
Signal source: SCART
You can use a Scart cable (not included) to connect other devices (e.g. a VCR or a satellite receiver)
to the LT 1510. The device has an interface connector (11) for this purpose.
SCART (Euro AV) cable
Connecting External Equipment with AV Output
Signal source: AV
You can use an AV cable (not included) to connect other devices (e.g. a camcorder or a game con-
sole) to the LT 1510. The device has the jacks (22) for the video (yellow) and (21) for the audio signal
(red, white).
AV cable (yellow, red, white)
