15
Connecting the Devices
EN
Connecting External Equipment with HDMI Interface
Signal source: HDMI
HDMI is the abbreviation for “High Denition Multimedia Interface” and allows the digital transmis-
sion of both audio and video signals. Use an HDMI cable (not included) to connect the output of a
playback device (e.g. a digital satellite receiver or DVD player) to the input (6) of your LT 1510.
HDMI cable
Connecting a PC
Signal source: PC
Use a VGA cable (not included in the package) to connect the graphics adapter output of a PC or
notebook with the VGA input (7) of your LT 1510. Please note that only the picture signal will be
transferred via this connector. In order to be able to listen to the sound transmitted by the computer,
use a 3.5 mm jack-type audio cable (not included) to connect the audio output (Line Out) of your
computer to the PC Audio In connector (8) of your LT 1510.
VGA cable
Audio cable
(3.5mm jack)
