GB
│
IE
│
NI
│
CY
│
9 ■
SAS 7.4 LI D3
4) Push the wall plugs into the holes and then screw the wall bracket 3 firmly
into place using the screws.
5) You can place the nozzles on the accessories holder on the side.
6) Connect the mains adapter
4 to a mains power socket.
Charging
NOTE
► Check to ensure that the on/off switch
6 has been pushed back (to the
position "0") before starting the charging process.
■ Place the handheld vacuum cleaner from above into the wall bracket
3 so
that the barrel plug 5 slips into the socket on the handheld vacuum cleaner.
The charge indicator lamp 7 lights up red and the charging process begins.
■ Important: The charge indicator lamp
7 lights up green once the
handheld vacuum cleaner is charged enough to vacuum again. This does
not mean that all the batteries are completely charged. When the charge
indicator lamp 7 lights up green, the batteries are charged to around 80%.
■ When charging is complete, which can take around 5 hours with fully dis-
charged batteries, the appliance automatically switches to a trickle charge
(maintenance function). Nevertheless, in order to avoid possible damage
to the batteries, do not leave the appliance permanently connected to the
mains adapter
4.
■ Do not recharge the batteries again until the handheld vacuum cleaner's suc-
tion power becomes appreciably weaker and the charge indicator
lamp
7 flashes green.
NOTE
► If the battery is completely discharged, the appliance switches off and
the charge indicator lamp
7 flashes green/red alternately for approx.
60 seconds. Start charging the appliance.
► The handheld vacuum cleaner can also be charged directly via the mains
adapter
4. To do this, remove the barrel plug 5 with a slight twist from
the wall bracket 3 and the cable from the cable routing. Insert the barrel
plug 5 into the socket on the handheld vacuum cleaner.
