2. Names of parts (see fold-out page)
1 Warning symbol - “Do not cover”
2 Control panel
3 Infrared receiver
4 Air outlet grille
5 Main switch ON/OFF
6 Base
7 Handle
8 Compartment for remote control
9 Air intake grille
10 Display
11 Function selector
12 Timer
13 Swivel function
14 Increase temperature
15 Reduce temperature
16 On/Off switch
17 Reduce temperature
18 Increase temperature
19 Timer
20 Swivel function
21 Function selector
22 On/Off switch
23 Remote control
3. Technical data
Power supply: 220 - 240 V
~
/50 Hz
Output: 1,000/2,000 watts
Protection class: II
Batteries for remote control: 2x type AAA/1.5 V
4. Safety information
4.1 Terms used
The following signalling terms are found in
these Operating Instructions:
Warning!
High risk. Disregarding the
warning may cause injury to life
and limb.
Caution!
Medium risk. Disregarding the warning may
cause damage to property.
Note:
Low risk. Circumstances that should be taken
into account when dealing with this
appliance.
4.2 General information
• Before using the appliance, be sure to
read these Operating Instructions
carefully. They are a component part of
the appliance and must be available at
all times.
• Use the appliance only for the purpose
described (see “1.1 Intended purpose”
on page 55).
• Check whether the mains voltage (see
type plate on the appliance) agrees with
your mains voltage.
• This device is not intended to be used by
individuals (including children) with
