28 GB/IE
Before use
Unpacking
NOTES:
o The 2 cooling packs [] and 4 casters[] are
stored inside the water tank
[] (Fig.G).
o The remote control [] is stored in the handle
storage on the back of the product (Fig.G).
1. Remove the packaging.
2. Check if all parts are complete.
3. Check if the product is damaged.
Inserting/Replacing the
battery
Fig. C
o For first time use: The button cell
(typeCR2025) is pre-installed inside the
remote control
[]. Pull out the insulation strip
from the battery compartment
[].
1. Open the battery compartment
[]: Remove
the battery receptacle (located at the back of
the remote control
[].
2. Remove the used battery, if present.
3. Insert a button cell (type CR2025) into the
battery receptacle. The + polarity marking has
to point upwards.
4. Slide the battery receptacle back into the
battery compartment
[].
5. Use a dry, lint-free cloth to clean the battery
contacts before inserting.
Filling the water tank
Fig. Action
D
Rotate the locking lever[] for the removable water tank [] counter-clockwise by
90°.
Slightly pull the removable water tank [] out of the product.
E
Fill the removable water tank [] with cool water.
Check the water level at the water gauge []: The water level must be above the
Min
mark and below the
Max
mark.
–
o After filling: Slide the removable water tank [] into the product.
o Rotate the locking lever[] for the removable water tank [] clockwise by 90° to lock
the removable water tank.
Operation
1. Insert 4 casters [] to all corners on the bottom
of the product (Fig. H).
2. Place the product on a flat, stable ground.
3. Connect the mains plug
[] to a suitable
socket-outlet.
4. Turning the product on: Press
[] or [].
5. Keep the remote control
[] in a safe place so
that it does not fall and break.
6. When you are not using the remote control
[]:
Store the remote control on the handle storage
on the back of the product.
