Cleaning the appliance
♦ Wipe the appliance with a damp cloth. For stubborn dirt, add a mild detergent to
the cloth. Ensure that the appliance is completely dry before using it again.
Cleaning the rotary brush
The rotary brush u should be checked regularly for blockages and any hair, threads
or dirt should be removed. To do this, remove the rotary brush u (see fig. 16):
♦ Turn the floor nozzle r over.
♦ Slide the release switch z of the rotary brush u towards the
symbol so that
you can remove the cover plate t.
♦ Lift out the rotary brush u.
♦ Use scissors to remove any hair and threads from the rotary brush u.
♦ To replace the rotary brush u, push the wide end onto the drive shaft first.
Then push the other end into the socket so that the rotary brush u lies straight in
the floor nozzle r.
♦ Replace the cover plate t and lock it by sliding the release switch z in the
direction of the
symbol.
Fig. 16
