16 GB/MT
After unpacking the product, check if all parts
are complete and in good condition. Remove
all packing materials (including protective foils)
before use.
1x Motor unit (with upper pole and 4 lock screws)
1x Base
1x Base weight
1x Extension pole and lower pole (with washer and
L-shaped bolt)
1x Front grille (with lock nut and lock screw)
1x Rear grille
1x Blade (with lock screw)
NOTE: Various removable components are
delivered pre-assembled (see “Description of
parts”).
Description of parts
Before reading, unfold the page containing the
illustrations and familiarise yourself with all the
functions of the product.
Fig. A
[1]
Blade
[2]
Rear grille
[3]
Grille handle
[4]
Motor shaft
[5]
Speed control knob (0, I, II, III)
[6]
Oscillation control knob
[7]
Power cord with power plug
[8]
*Screw and nut
[9]
*Knob (tilt adjustment)
[]
Motor unit (with upper pole)
[]
*Lock screw (motor bracket)
[]
*Height adjustment knob
[]
Extension pole
[]
Base
[]
Base weight
[]
*Washer
[]
*L-shaped bolt
[]
*Lock screw (M5 x 8 mm) (x 4) (rear grille)
[]
*Lock screw (M4 x 8 mm) (blade)
[]
Grille clips (x 5)
[]
*
Lock nut and lock screw (M2.5 x 10 mm)
(grille)
[]
Front grille
[]
Grille hanger
* pre-assembled
Technical data
Input voltage: 220–240 V
~~
, 50–60 Hz
Power consumption: 45 W
Description Symbol Value Unit
Maximum fan
flow rate
F 65.93 m
3
/min
Fan power input P 41.3 W
Service value SV 1.60 (m
3
/min)/W
Standby power
consumption
P
SB
0.0 W
Fan sound power
level
L
WA
63.77 dB(A)
Maximum air
velocity
C 3.61 meters/sec
Measurement
standard for
service value
IEC 60879:1986 (corr. 1992)
Contact details
for obtaining
more information
OWIM GmbH & Co. KG
Stiftsbergstraße 1
74167 Neckarsulm
GERMANY
www.owim.com
