Silverline 3170 EC - Roof Cowls;Roof Seal Kit

Page 18
7. Installation
Roof Cowls / Roof Seal Kit
1
2
34
WARNING
All electrical wiring should be kept inside the roof space.
*NOTE: Motor system does not include the roof seal kit/roof cowls, cable tie, duct tape or the
support straps.
For best result, please install ducting in a straight line and duct length no longer than 4 metres.
Main Power Lead (Male Plug)
Roof Cowls*
Flexi Ducting must be pulled
taut. DO NOT crush or kink the
ducting.
&RQQHFWÁH[LGXFWLQJWRWKH
outlet on rangehood using duct
tape or cable tie. Please DO
NOT rip the ducting.
4
1
2
3
