12V Lithium Power Bank & Jump Starter 423352
5
silverlinetools.com
Jump Starter Safety
• Do not allow positive and negative lead clamps to make contact. Live clamps that come into
contactwitheachothercouldresultintheleadsmelting,and/orcreatearehazard
• Do not attempt to jump start any vehicle whose battery is leaking, cracked, or otherwise damaged
• Do not attempt to jump start a vehicle with a frozen battery. Exercise caution when bringing such
a battery into a building as there is a possibility the battery could leak when it returns to
normal temperature
• Unless the battery in the vehicle is of the ‘maintenance-free’ type, always check that the
electrolyte level is correct before attempting to jump start the vehicle
• Lead-acidbatteriesemitexplosive,ammablegases,particularlyduringattemptsatstarting
a vehicle. DO NOT SMOKE and do not expose the jump starter or vehicle’s battery to any open
amesorhightemperaturesurfaces.Theleadacidbatteryinavehicleistheprimaryconcernfor
ammablegas
• Only use in well-ventilated areas
• Always wear protective gloves and goggles when handling lead acid batteries
• Always remove all metal jewellery before handling lead acid batteries
• Be aware that loose clothing and long hair could get caught in moving engine parts. When using
this product, tie up hair and secure loose clothing
• Wash thoroughly with soap and water if battery acid contacts skin or clothing. If battery acid
contacts eyes, wash thoroughly with clean water and seek medical help
• Only use this jump starter in completely dry conditions
• If the Jump Starter becomes swollen during use or when charging, IMMEDIATELY DISCONNECT
Jump Starter from the cables or power supply and discontinue use
• If at any time the Jump Starter begins to swell, smoke, or become hot to the touch, IMMEDIATELY
DISCONNECT the Jump Starter and discontinue use
Lithium Polymer and Other Battery
Safety
WARNING: Lithium polymer batteries are volatile. If lithium polymer batteries are incorrectly
used,storedorchargedtheycanbecomeare,burnand/orexplosionhazard.
• Keep the battery out of reach of children
• ONLYchargelithiumpolymerbatteriesusingthechargerprovidedordesignedspecicallyfor
your product
• Allow batteries to cool for 15 minutes after charging or heavy use. Failure to follow these
instructionsmaycauseoverheatingorre
• When not in use, batteries should be stored at room temperature (approximately 20°C)
• Ensure that battery contacts cannot accidentally short in storage. Keep batteries clean; foreign
objects or dirt may cause a short. Keep away from other metal objects, for example, paper clips,
coins, keys, nails and screws
• Under abusive conditions, liquid may be ejected from the battery. This liquid may cause skin
irritationorburns.Avoidcontact.Ifcontactaccidentallyoccurs,ushwithwater.Ifliquidcontacts
eyes, seek medical help
• DONOTopen,disassemble,crush,heatabove60°Corincinerate.Donotdisposeofinre
or similar
• Never allow a metal tool to concurrently touch both the positive and negative cable/clamp ends
or battery terminals
• Be sure to have someone close by you when you are working with electricity and batteries,
particularly lead acid batteries
• Ifthevehiclebatteryneedstoberemoved,alwaysremovethenegative/blackterminalrst,
followed by the positive/red terminal. Ensure ALL vehicle electrical accessories are switched OFF
before removing the battery
• If working with lead acid batteries, ensure there is water, soap, and bicarbonate of soda readily
available, just in case there is any skin contact with battery acid
1 Lithium Polymer Battery Pack
2 Power Button
3 LED Power Indicator Lights
4 IN Charging Port
5 USB Output Port
6 LED Light
7 High Current Positive Output
8 High Current Negative Output
9 Black Negative Clamp
10 Red Positive Clamp
11 Power Supply Cord
12 High Current Connector Plug
13 Smart Jump Start Protector Unit
14 Jump Start Protector Reset Button
15 Jump Start Protector LED
Product Familiarisation
Intended Use
Lithium polymer power bank used as a portable, high-current DC jump starter. Power bank is also
capable of charging or powering other portable devices via the USB output, and has an LED torch
lightwithashing,safetymodes,includingSOS.
Unpacking Your Tool
• Carefully unpack and inspect your new Lithium Jump Starter. Familiarise yourself with all its
features and functions
• Ensure that all parts of the tool are present and in good condition. If any parts are missing or
damaged, have such parts replaced before attempting to use this tool
Before Use
Charging the Lithium Jump Starter
IMPORTANT: The Jump Starter should be fully charged before initial use. Always charge the
Jump Starter on a hard surface away from combustible materials and do not leave unattended
while charging.
1. Plug the Power Supply Cord (11) into the IN Charging Port (4) and the other end into a 100–240V
AC power outlet
2. Turn the power outlet on to charge the Lithium Jump Starter
Note: To check the charge state of the Lithium Jump Starter press the Power Button (2) and the LED
Power Indicator Lights (3) will illuminate. The number of illuminated LED lights indicates charge
level: 1=20%; 2=40%; 3=60%; 4=80%; and 5=100%.
Note:Whencharging,theLEDPowerIndicatorLightswillashsequentially.Aschargingprogresses,
the lights illuminate solidly without blinking. The more lights that are illuminated solidly, the higher
the charge level. The Lithium Jump Starter is fully charged (100%) when all LED Power Indicator
Lights are illuminated solidly without blinking.
WARNING: Should the Lithium Jump Starter begin to beep and stop charging during the
charging process, IMMEDIATELY DISCONNECT from the power outlet and Power Supply Cord and
discontinue use. (Refer to troubleshooting.)
Operation
WARNING: If at any time the Jump Starter begins to swell, smoke, or become hot to the touch,
IMMEDIATELY DISCONNECT the Jump Starter, if connected, and discontinue use.
Note: When the lithium polymer power bank’s power store becomes too low to supply any charge,
the device may beep and shut down. The power bank will require recharging. (See ‘Charging the
Lithium Jump Starter’.)
