42C System Operations - 19
Be certain the water heater is full of
water and does not contain air. If the
water heater is not full of water, dam-
age to the heating elements may result
when electrical power is turned ON to
the unit.
Forward Air Conditioner: Supplies pow-
er to the forward air conditioner. Air pump
must be ON before unit is turned ON.
Mid Air Conditioner: Supplies power to
the mid air conditioner (if equipped with
the optional 37,000 BTU system).
Icemaker: Supplies power to the icemak-
er unit.
Air Pump: Supplies power to the air con-
ditioner raw water pump.
Vacuum System: Supplies power to the
optional central vacuum cleaner system.
Range: Supplies power to the stove/oven
combination.
Spare: Supplies power to additional AC
accessories.
Spare: Supplies power to additional AC
accessories.
Spare: Supplies power to additional AC
accessories.
Spare: Supplies power to additional AC
accessories.
Shore Power
Follow the procedures below to connect
shore power to your yacht:
• Turn OFF all 115 volt circuit breakers
at the AC portion of the AC/DC Panel.
Shut down the generator if it is in opera-
tion.
Using a damaged or improper cord for
shore power connection can cause
electrical shock and serious personal
injury. Use a cord specifi cally designed
for shore power connection. DO NOT
use a household extension cord.
• Connect the female end of the shore
power cord to the yacht’s inlet recepticle.
Be certain the lock ring is tightly secured.
If there is a cord already supplied at the
dock, be sure to unhook the cord from the
dockside outlet.
DO NOT connect the shore power cord
to the dockside electrical source fi rst.
You can accidentally drop the cord into
the water which may result in electrical
shock and serious personal injury.
• Connect the Shore Power Cable to
power supply. When connecting the shore
power cable to the dockside outlet, be
certain the cable has suffi cient slack to
prevent stretching during tidal changes.
• Slide the SHORE POWER/GENERA-
TOR slide bar over on top of the generator
side of the switch. With the slide over, turn
on the shore power switch.
